Datsun Fairlady 1600 (R16) Carburetor ("SU")
Datsun Fairlady Parts illustration no. 008-1 Carburetor 1600 (R16) "SU" [1]

008 -1  Carburetor 1600 (R16) "SU" [1]
KeyPart No.ModelApplied DateQty
FromTo
1ASSY-CARBURETOR (HJB38W-3)
  16010-14605 1.6L   -   1
2ASSY-CARBURETOR (HJB38W-3)
  16010-14605 1.6L   -   1
3ASSY-CARBURETOR (HJB38W-3)
  16010-14605 1.6L   -   1
4ASSY-CARBURETOR (HJB38W-3) (ISO)
  16010-146051.6L (EXC SPLU)   -   1
5ASSY-CARBURETOR (HJB38W-3)
  16010-146051.6L (EXC EXHAUST & EVAPO)   -   1
6CARBURETOR FRONT
  16010-146351.6L (EXC EXHAUST & EVAPO)   -   1
7CARBURETOR REAR
  16010-146551.6L (EXC EXHAUST & EVAPO)   -   1
8ASSY-CARBURETOR (HJB38W-3B)
  16010-14702 SPLU   -   1
9ASSY-CARBURETOR (ISO) (HJB38W-5AK)
  16010-14702SPLU   -   1
10ASSY-CARBURETOR (ISO) (HJB38W-5AK)
  16010-14702SPLU   -   1
11ASSY-CARBURETOR (HJB38W-6)
  16010-A77011.6L EXHAUST & EVAPO   -   1
12ASSY-CARBURETOR (HJB38W-6)
  16010-A77011.6L EXHAUST & EVAPO   - 69091
13CARBURETOR FRONT
  16010-A77321.6L EXHAUST & EVAPO   -   1
14CARBURETOR FRONT
  16010-A77321.6L EXHAUST & EVAPO   -   1
15CARBURETOR REAR
  16010-A77511.6L EXHAUST & EVAPO   -   1
  16010-A77521.6L EXHAUST & EVAPO   -   1
16CARBURETOR REAR
  16010-A77511.6L EXHAUST & EVAPO   -   1
17SCREW 5D
  16129-730131.6L   -   8
18SCREW 5D
  16129-730131.6L   -   8
19WASHER-SPRING
  16086-001001.6L (EXC SPLU)   -   8
20WASHER-SPRING 5D
  23109-30000SPLU   -   8
21WASHER-SPRING 5D
  23502-30000SPLU   -   8
22NUT-OIL CAP
  16341-104101.6L   -   2
23NUT-OIL CAP
  16341-104101.6L   -   2
24PACKING (GASKET)
  16342-104001.6L   -   2
25PLUNGER-OIL DAMPER
  16343-122101.6L   -   2
26WASHER-OIL DAMPER
  16344-104001.6L   -   2
27RING-C
  16345-104001.6L   -   2
28SPRING-SUCTION
  16346-122101.6L   -   2
29PACKING-NYLON, 12.5 (GASKET)
  16347-104001.6L   -   2
30LIFTER-PISTON
  16324-104001.6L   -   2
31SPRING-PISTON LIFTER
  16325-104001.6L   -   2
32RING-E
  16326-104001.6L   -   2
33JET-NEEDLE M-39
  16354-146101.6L   -   2
34JET NEEDLE M-70
  16354-A77101.6L   -   2

JET-NEEDLE M-43
  16354-158101.6L   -   2
35SCREW-SET, JET NEEDLE
  16219-104001.6L   -   2
36NOZZLE
  16355-146101.6L (EXC SPLU)   -   2
37NOZZLE
  16355-H2310SPLU   -   2
38SLEEVE-NOZZLE
  16351-104001.6L   -   2
39SCREW-SET, NOZZLE SLEEVE
  16027-104001.6L   -   2
40WASHER-10D
  16130-104001.6L (EXC SPLU)   -   2
41WASHER-10D
  16130-25610SPLU   -   2
42SPRING-IDLE ADJUST SCREW
  16145-104001.6L   -   2
43NUT-IDLE ADJUST
  16144-122101.6L   -   2
44NUT-IDLE ADJUST
  16144-25610SPLU   -   2
45SHAFT-THROTTLE
  16122-122101.6L   -   2
46VALVE-THROTTLE
  16120-104001.6L   -   2
47SCREW-VALVE
  16121-851601.6L (EXC SPLU)   -   4
48SCREW-VALVE
  16121-85060SPLU   -   4
49COVER-FLOAT CHAMBER
  16125-104001.6L   -   2
50COVER-FLOAT CHAMBER
  16125-104001.6L   -   2
51COVER-FLOAT CHAMBER
  16125-E32101.6L   -   2
52GASKET-FLOAT CHAMBER
  16064-220101.6L   -   2
53GASKET-FLOAT CHAMBER
  16064-220101.6L   -   2
54SCREW-SET, 5
  16065-080101.6L   -   8
55WASHER-SPRING
  16086-001001.6L   -   8
56ASSY-FLOAT
  16061-K14071.6L   -   2
57LEVER-FLOAT
  16062-104001.6L   -   2
58SHAFT-FLOAT LEVER
  16066-104001.6L (EXC SPLU)   -   2
59SHAFT-FLOAT LEVER
  16066-25610SPLU   -   2
60ASSY-VALVE, NEEDLE
  16101-104001.6L   -   2
61WASHER-10D
  16094-104001.6L (EXC SPLU)   -   2
62WASHER-10D
  16130-22010SPLU   -   2
63NIPPLE-FUEL (VALVE-RETURN)
  16111-A7715 1.6L   -   2
64NIPPLE-FUEL (F) (VALVE-RETURN)
  16111-A77151.6L   -   2
65NIPPLE-FUEL (F) (VALVE-RETURN)
  16111-A77151.6L   -   2
66BOLT-FILTER
  16108-180101.6L   -   2
67FILTER
  16098-734011.6L   -   2
68PACKING-12 (WASHER)
  16094-765001.6L   -   2
69PACKING-12 (WASHER)
  16094-765001.6L   -   2
70SCREW-SET, NIPPLE
  16331-104001.6L   -   2
71PACKING-10 (GASKET)
  16335-146101.6L   -   2
72VALVE FUEL RETURN FOR 16010-14701
  16111-14715SPLU   -   1
73VALVE FUEL RETURN W/BRACKET FOR 16010-14702
  16111-A7711SPLU   -   1
  16111-A7712 SPLU   -   1
74VALVE FUEL RETURN W/BRACKET FOR 16010-A7700
  16111-A7711SPLU   -   1
  16111-A7712 SPLU   -   1
75VALVE FUEL RETURN W/BRACKET FOR 16010-A7700
  16111-A7711SPLU   -   1
76KIT-BRACKET FUEL CONNECTOR FOR 16010-14700
  16111-25615SPLU   -   1
77KIT-BRACKET FUEL CONNECTOR FOR 16010-14701
  16111-25615SPLU   -   1
78PIPE-FUEL
  16356-122101.6L (EXC SPLU)   -   2
79PIPE-FUEL
  16356-25610SPLU   -   2
80PIPE-FUEL
  16356-25610SPLU   -   2
81SLEEVE
  16357-122101.6L   -   2
82NUT-SLEEVE
  16359-122101.6L   -   2
83CLIP
  A6358-E4310 1.6L   -   4
84CLIP
  A6358-E43101.6L   -   4
85PLATE-THROTTLE ADJUST
  16127-146101.6L   -   2
86WASHER-8
  16084-146101.6L   -   2
87LEVER-IDLE FIRST
  16277-146111.6L   -   2
88LEVER-IDLE FIRST
  16277-146111.6L   -   2
89SLEEVE-CHOKE
  16239-146101.6L   -   2
90LEVER-THROTTLE
  16134-146101.6L   -   2
91WASHER
  23109-300001.6L   -   2
92NUT-8
  16214-850601.6L   -   2
93SPRING-THROTTLE ADJUST SCREW
  16193-104001.6L   -   2
94SCREW-THROTTLE ADJUST
  16114-104001.6L   -   2
95SPRING-STARTER RETURN
  16190-H27101.6L   -   2
96WASHER-5
  16072-146101.6L   -   2
97PLATE-CONNECT
  16147-146111.6L (EXC SPLU)   -   2
98PLATE-CONNECT
  16147-14710SPLU   -   2
99SLEEVE
  16116-146101.6L   -   2
100SPRING-CONNECT
  16157-146101.6L   -   2
101LEVER-CHOKE
  16238-146101.6L   -   2
102BOLT
  16185-146101.6L   -   2
103WASHER-7
  16217-104011.6L   -   2
104WASHER-SPRING
  16076-146101.6L   -   2
105BOLT-5
  16185-104001.6L   -   2
106ROD-CONNECTING
  16248-146101.6L   -   2
107PIN-COTTER
  16091-105601.6L   -   2
108WASHER-4D
  16220-146101.6L (EXC SPLU)   -   2
109WASHER-4D
  22185-50000SPLU   -   2
110SLEEVE
  16123-146101.6L   -   2
111WASHER-SPRING
  22156-850601.6L   -   2
112SCREW-4
  23552-094001.6L   -   2
113WASHER
  23109-300001.6L   -   2
114BOLT
  16322-122101.6L   -   2
115SPRING-THROTTLE
  16194-122101.6L (EXC SPLU)   -   2
116SPRING-THROTTLE
  16194-14710SPLU   -   2
117PLATE-CONNECT
  16147-146101.6L   -   2
118PIN-COTTER
  16091-105601.6L   -   2
119NUT-CARBURETOR TO MANIFOLD
  00911-245101.6L   - 67028
120NUT-CARBURETOR TO MANIFOLD
  08911-608001.6L6703 -   4
121WASHER-SPRING, CARBURETOR TO MANIFOLD
  00915-115101.6L   - 67024
122WASHER-SPRING, CARBURETOR TO MANIFOLD
  08915-1381A1.6L6703 -   4
123WASHER-PLAIN, CARBURETOR TO MANIFOLD
  00915-415001.6L   - 67024
124WASHER-PLAIN, CARBURETOR TO MANIFOLD
  08915-4361A1.6L6703 -   4
125BOLT-HEAT SHIELD PLATE TO CARBURETOR
  00111-514101.6L   - 67024
126BOLT-HEAT SHIELD PLATE TO CARBURETOR
  08110-814101.6L6703 -   4
127WASHER-SPRING, TO ATTACH CARBURETOR
  00915-115101.6L   - 67024
128WASHER-HEAT SHIELD PLATE TO CARBURETOR
  00915-115101.6L   - 67024
129REPAIR KIT-A, CARBURETOR (INC 25, 32, 34, 36, WASHER)
  16010-146251.6L   -   1
130REPAIR KIT-A, CARBURETOR
  16010-146251.6L   -   1
131REPAIR KIT-B, CARBURETOR
  16010-146261.6L   -   1
132REPAIR KIT-B, CARBURETOR
  16010-146261.6L   -   1
133REPAIR KIT-D, CARBURETOR
  16010-146281.6L   -   1
134REPAIR KIT-D, CARBURETOR
  16010-146281.6L   -   1
135SHAFT THROTTLE
  16361-146001.6L   - 67021
136SHAFT-THROTTLE
  16361-146011.6L6703 -   1
137ASSY-DRUM, THROTTLE
  16362-146011.6L   - 67021
138ASSY-DRUM, THROTTLE
  16362-146011.6L6703 -   1
139CLIP-THROTTLE WIRE
  16364-146001.6L   - 67021
140CLIP-THROTTLE WIRE
  16364-146011.6L6703 -   1
141SCREW
  00369-012101.6L   -   1
142ARM-THROTTLE SHAFT
  16365-146001.6L   - 67022
143ARM-THROTTLE SHAFT
  16365-146011.6L6703 -   2
144ARM-THROTTLE ADJUST SCREW
  16367-146001.6L   - 67021
145ARM-THROTTLE ADJUST SCREW
  16367-146011.6L6703 -   1
146SCREW
  00334-020101.6L   -   4
147WASHER-TOOTH
  00916-410101.6L   -   4
148ROD-CONNECTING
  16370-146001.6L   - 67022
149ROD-CONNECTING
  16370-146011.6L6703 -   2
150TURN-BACKLE, CONNECTING ROD
  16373-146001.6L   - 67022
151TURN-BACKLE, CONNECTING ROD
  16373-146051.6L6703 -   2
152TURN-BACKLE, CONNECTING ROD
  16373-146051.6L6703 -   2
153NUT
  16374-146001.6L   - 67022
154NUT
  16374-188101.6L6703 -   2
155NUT
  16375-146001.6L   - 67022
156NUT
  16375-188101.6L6703 -   2
157SCREW TO FIX BRACKET
  00369-012101.6L   -   2
158WASHER-LOCK TO FIX BRACKET
  00915-110101.6L   -   2
159TUBE-FLEXIBLE, FUEL PUMP TO CARBURETOR (FRONT)
  17524-122001.6L   -   1
160TUBE-FLEXIBLE, FUEL PUMP TO CARBURETOR (REAR)
  17525-122001.6L   -   1
  A8742-200201.6L   -   1
161CLAMP-TUBE (HOSE)
  01555-001911.6L   -   4
162CONNECTOR-VACUUM TUBE
  16020-188101.6L   -   1
SHAFT-THROTTLE TUBE-FLEXIBLE, FUEL PUMP TO CARBURETOR (FRONT) CLAMP-TUBE (HOSE) SCREW-SET, NIPPLE SLEEVE COVER-FLOAT CHAMBER VALVE FUEL RETURN W/BRACKET FOR 16010-14702 / VALVE FUEL RETURN W/BRACKET FOR 16010-A7700 LEVER-FLOAT ASSY-FLOAT WASHER-SPRING / WASHER-SPRING 5D PLUNGER-OIL DAMPER WASHER-SPRING SHAFT-FLOAT LEVER CLAMP-TUBE (HOSE) SCREW-SET, JET NEEDLE VALVE-THROTTLE COVER-FLOAT CHAMBER WASHER BOLT SLEEVE-NOZZLE WASHER-10D SPRING-PISTON LIFTER NOZZLE PIPE-FUEL WASHER-4D WASHER-10D ASSY-VALVE, NEEDLE GASKET-FLOAT CHAMBER SCREW 5D NUT-OIL CAP PACKING (GASKET) WASHER-OIL DAMPER RING-C NIPPLE-FUEL (F) (VALVE-RETURN) PACKING-12 (WASHER) SCREW-SET, 5 TUBE-FLEXIBLE, FUEL PUMP TO CARBURETOR (REAR) SPRING-SUCTION PACKING-NYLON, 12.5 (GASKET) JET-NEEDLE / JET NEEDLE SCREW-VALVE SHAFT-THROTTLE SCREW-SET, NOZZLE SLEEVE NUT-IDLE ADJUST SPRING-PISTON LIFTER LIFTER-PISTON RING-E CLIP SLEEVE NUT-SLEEVE COVER-FLOAT CHAMBER PLUNGER-OIL DAMPER RING-C NUT-OIL CAP PLUNGER-OIL DAMPER WASHER-OIL DAMPER RING-C WASHER-10D ASSY-FLOAT SHAFT-FLOAT LEVER SPRING-SUCTION VALVE-THROTTLE ASSY-VALVE, NEEDLE LEVER-FLOAT RING-E SPRING-SUCTION SPRING-PISTON LIFTER RING-E SLEEVE-NOZZLE SPRING-IDLE ADJUST SCREW LIFTER-PISTON CLIP SPRING-IDLE ADJUST SCREW SCREW-SET, NOZZLE SLEEVE WASHER BOLT SPRING-THROTTLE VALVE-THROTTLE PLATE-CONNECT SPRING-STARTER RETURN WASHER-5 SPRING-CONNECT PIN-COTTER WASHER-7 SLEEVE-CHOKE WASHER-7 SLEEVE WASHER NUT-8 SCREW SCREW WASHER-TOOTH SHAFT THROTTLE / SHAFT-THROTTLE NUT / NUT ROD-CONNECTING FILTER NUT-OIL CAP PACKING (GASKET) WASHER-OIL DAMPER FILTER COVER-FLOAT CHAMBER PACKING (GASKET) NIPPLE-FUEL (VALVE-RETURN) LEVER-FLOAT RING-E JET-NEEDLE PACKING-NYLON, 12.5 (GASKET) WASHER-10D SHAFT-FLOAT LEVER ASSY-FLOAT JET-NEEDLE PACKING-NYLON, 12.5 (GASKET) CLIP LIFTER-PISTON NUT-SLEEVE SCREW-SET, NIPPLE SCREW-SET, NOZZLE SLEEVE NUT-IDLE ADJUST SPRING-PISTON LIFTER RING-E CLIP SCREW-SET, NIPPLE NUT-IDLE ADJUST WASHER-SPRING SLEEVE-NOZZLE WASHER-4D PLATE-CONNECT LEVER-IDLE FIRST ROD-CONNECTING WASHER-SPRING CLIP-THROTTLE WIRE ARM-THROTTLE SHAFT ASSY-DRUM, THROTTLE NUT TURN-BACKLE, CONNECTING ROD ARM-THROTTLE ADJUST SCREW SCREW SPRING-THROTTLE ADJUST SCREW SPRING-STARTER RETURN SPRING-CONNECT LEVER-CHOKE SPRING-THROTTLE SLEEVE WASHER-SPRING SCREW-4 PLATE-CONNECT PIN-COTTER WASHER NUT-8 ROD-CONNECTING SLEEVE-CHOKE ARM-THROTTLE ADJUST SCREW NUT TURN-BACKLE, CONNECTING ROD WASHER-TOOTH ARM-THROTTLE SHAFT SCREW-THROTTLE ADJUST PLATE-THROTTLE ADJUST LEVER-IDLE FIRST WASHER-8 WASHER-5 PLATE-CONNECT BOLT WASHER-4D BOLT-5 WASHER-4D PIN-COTTER LEVER-IDLE FIRST LEVER-THROTTLE CLIP-THROTTLE WIRE SCREW ASSY-DRUM, THROTTLE SHAFT THROTTLE / SHAFT-THROTTLE ARM-THROTTLE SHAFT ROD-CONNECTING TURN-BACKLE, CONNECTING ROD NUT / NUT
SHAFT-THROTTLE TUBE-FLEXIBLE, FUEL PUMP TO CARBURETOR (FRONT) CLAMP-TUBE (HOSE) SCREW-SET, NIPPLE SLEEVE COVER-FLOAT CHAMBER VALVE FUEL RETURN W/BRACKET FOR 16010-14702 / VALVE FUEL RETURN W/BRACKET FOR 16010-A7700 LEVER-FLOAT ASSY-FLOAT WASHER-SPRING / WASHER-SPRING 5D PLUNGER-OIL DAMPER WASHER-SPRING SHAFT-FLOAT LEVER CLAMP-TUBE (HOSE) SCREW-SET, JET NEEDLE VALVE-THROTTLE COVER-FLOAT CHAMBER WASHER BOLT SLEEVE-NOZZLE WASHER-10D SPRING-PISTON LIFTER NOZZLE PIPE-FUEL WASHER-4D WASHER-10D ASSY-VALVE, NEEDLE GASKET-FLOAT CHAMBER SCREW 5D NUT-OIL CAP PACKING (GASKET) WASHER-OIL DAMPER RING-C NIPPLE-FUEL (F) (VALVE-RETURN) PACKING-12 (WASHER) SCREW-SET, 5 TUBE-FLEXIBLE, FUEL PUMP TO CARBURETOR (REAR) SPRING-SUCTION PACKING-NYLON, 12.5 (GASKET) JET-NEEDLE / JET NEEDLE SCREW-VALVE SHAFT-THROTTLE SCREW-SET, NOZZLE SLEEVE NUT-IDLE ADJUST SPRING-PISTON LIFTER LIFTER-PISTON RING-E CLIP SLEEVE NUT-SLEEVE COVER-FLOAT CHAMBER PLUNGER-OIL DAMPER RING-C NUT-OIL CAP PLUNGER-OIL DAMPER WASHER-OIL DAMPER RING-C WASHER-10D ASSY-FLOAT SHAFT-FLOAT LEVER SPRING-SUCTION VALVE-THROTTLE ASSY-VALVE, NEEDLE LEVER-FLOAT RING-E SPRING-SUCTION SPRING-PISTON LIFTER RING-E SLEEVE-NOZZLE SPRING-IDLE ADJUST SCREW LIFTER-PISTON CLIP SPRING-IDLE ADJUST SCREW SCREW-SET, NOZZLE SLEEVE WASHER BOLT SPRING-THROTTLE VALVE-THROTTLE PLATE-CONNECT SPRING-STARTER RETURN WASHER-5 SPRING-CONNECT PIN-COTTER WASHER-7 SLEEVE-CHOKE WASHER-7 SLEEVE WASHER NUT-8 SCREW SCREW WASHER-TOOTH SHAFT THROTTLE / SHAFT-THROTTLE NUT / NUT ROD-CONNECTING FILTER NUT-OIL CAP PACKING (GASKET) WASHER-OIL DAMPER FILTER COVER-FLOAT CHAMBER PACKING (GASKET) NIPPLE-FUEL (VALVE-RETURN) LEVER-FLOAT RING-E JET-NEEDLE PACKING-NYLON, 12.5 (GASKET) WASHER-10D SHAFT-FLOAT LEVER ASSY-FLOAT JET-NEEDLE PACKING-NYLON, 12.5 (GASKET) CLIP LIFTER-PISTON NUT-SLEEVE SCREW-SET, NIPPLE SCREW-SET, NOZZLE SLEEVE NUT-IDLE ADJUST SPRING-PISTON LIFTER RING-E CLIP SCREW-SET, NIPPLE NUT-IDLE ADJUST WASHER-SPRING SLEEVE-NOZZLE WASHER-4D PLATE-CONNECT LEVER-IDLE FIRST ROD-CONNECTING WASHER-SPRING CLIP-THROTTLE WIRE ARM-THROTTLE SHAFT ASSY-DRUM, THROTTLE NUT TURN-BACKLE, CONNECTING ROD ARM-THROTTLE ADJUST SCREW SCREW SPRING-THROTTLE ADJUST SCREW SPRING-STARTER RETURN SPRING-CONNECT LEVER-CHOKE SPRING-THROTTLE SLEEVE WASHER-SPRING SCREW-4 PLATE-CONNECT PIN-COTTER WASHER NUT-8 ROD-CONNECTING SLEEVE-CHOKE ARM-THROTTLE ADJUST SCREW NUT TURN-BACKLE, CONNECTING ROD WASHER-TOOTH ARM-THROTTLE SHAFT SCREW-THROTTLE ADJUST PLATE-THROTTLE ADJUST LEVER-IDLE FIRST WASHER-8 WASHER-5 PLATE-CONNECT BOLT WASHER-4D BOLT-5 WASHER-4D PIN-COTTER LEVER-IDLE FIRST LEVER-THROTTLE CLIP-THROTTLE WIRE SCREW ASSY-DRUM, THROTTLE SHAFT THROTTLE / SHAFT-THROTTLE ARM-THROTTLE SHAFT ROD-CONNECTING TURN-BACKLE, CONNECTING ROD NUT / NUT
